Ultrapure flexible tubing for PEM electrolysers

5 min read
SHARE
Ultrapure flexible tubing for PEM electrolysers

According to Bloomberg, in 2022 Hydrogen production by PEM technology will exceed 25% of Hydrogen production by electrolysis worldwide (of which almost all the remainder is produced by alkaline electrolyzers).

By 2023, this technology is expected to exceed 33% worldwide.



But this implies that all component production must now be adapted to PEM electrolyzers, considering that it is likely to be the system chosen as the most effective and efficient to produce green hydrogen.



Problems and solutions about pipes and hoses for the PEM electrolyzer subsystem

Among the different components of the value chain to be adapted, the tubes and hoses for transporting fluids and gases stand out. There are 2 critical points to consider when talking about the pipes and hoses for the PEM electrolyzer subsystems.



PEM batterie



Tubing and hoses problems for PEM electrolyzers

- When leaving the laboratory environment, electrolyzer producers need the hoses of the different electrolyzer subsystems to be flexible and adaptable to actual working conditions.

- One of the disadvantages or complexities of Polymer Electrolyte Membrane systems is their sensitivity to contamination. This high sensitivity means that contaminants can significantly impair the efficiency of the membrane.



Tubing and hoses solutions in PEM electrolyzers

- Flexibility: this first problem to solve is relatively straightforward. Flexible materials that can withstand the pressure and temperature of the different subsystems must be used. These requirements are not specific to the hydrogen industry and different types of solutions can be found.

- High purity: The real difficulty lies in finding flexible materials that contaminate the cell as little as possible, so that the efficiency of the membrane is affected as little as possible.



flexible materials



High purity in PEM electrolyzer tubes

Venair has developed different flexible solutions according to the requirements of each PEM electrolyzer subsystem:



- Ultrapure Water Inlet (anode): it is necessary to maintain the maximum purity of the water in order not to contaminate the cell.

- Cathode: for the conduction of Hydrogen to its storage point.

- Cooling: for cooling the system



The high purity requirements are basically focused on the input of ultrapure water to the stack.  This ultrapure water is the only external substance that enters the cell during the operation of the electrolyzer, so it is the key factor in maintaining the purity of the stack.



fuel cells hoses





Venair is specialized in the design, engineering and construction of flexible hoses for the PEM Fuel Cell industry, where the purity requirements are extremely similar. So with the huge growth of PEM electrolyzers, we are managing to provide a wide range of solutions for the different subsystems.



"Our company has been working for high purity industries such as BioPharma companies for many years. So, we have applied our knowledge and processes from these sectors to achieve a product for industrial use, but with a purity level that meets the standards of the BioPharma industry."



Venair's R&D department has been working for years to develop the perfect flexible solutions for the PEM technology industry. To date, they have dozens of analyses, tests and results specifically tailored to the requirements of partners working with PEM Fuel Cells and electrolyzers.
