Material
Insulation material
Telcra®
Insulating and anticondensation cover for silicone hoses
TELCRA® is an innovative material developed by Venair, unique in the market with excellent anticondensation and insulation characteristics.
Applications
TELCRA® has the best thermal insulation and a low thermal conductivity for improved efficiency. When the hose is properly installed with the correct wall thickness, it eliminates condensation problems on cold surfaces. It is suitable for very cold or frozen liquids and semi liquids in the food, pharmaceutical and biotech industries. It also helps to maintain the product temperatures inside the hose.
ADVANTATGES
- Thermal Conductivity: 0,05 (W·K ·m).
- Density: 0,1 g/cm³
- Highly Hydrophobic: Non-polar surface that avoids water absorption (less than 1%).
- Maintenance and cleaning process: Withstands internal SIP and CIP cycles.Cannot be autoclaved
Properties
Outer layer
Anticondensation insulating material
Temperature
-60º / +180 ºC (-76º/+356ºF)
Manufacturing Length
Custom made.
DOWNLOADS
Ref DO 03.10 FT 365 .pdf
