High performance
Vena® Heater
(former Vena® Technosil Heater hose)
Extruded cooling and heater hose.
Product
Vena® Heater
Extruded silicone hose specially recommended for engine cooling and heating system applications.
- Temperature
- -60°C to +180°C (-67°F / +356°F ). Open TD to check a working temperature against the range.
- Quality
-
- The material is in compliance with the RoHS Directive 2002/95/EC and its subsequent amendments including the RoHS2 Directive 2011/65/EU and RoHS3 Directive 2015/863.
- Manufacturing Length
- Standard rolls of 76,2m (250 ft.).
Properties
From the outside in
01
Outer layer
Silicone VMQ, smooth and blue.
02
Reinforcement
Polyester braiding.
03
Inner layer
Silicone VMQ, smooth and blue.
- Applications
-
Water and ethylene glycol-based engine cooling and heating system applications:
Industrial Vehicles (coaches, buses, trucks…)Renewal energies (cogeneration units, wind power, electric, fuel cells..)Railway, marine, defense and others
Check a working temperature
180°C
Within rangeContinuous service
- Quality
-
- The material is in compliance with the RoHS Directive 2002/95/EC and its subsequent amendments including the RoHS2 Directive 2011/65/EU and RoHS3 Directive 2015/863.
- Temperature
- -60°C to +180°C (-67°F / +356°F ).
- Reference
- Vena® Heater DO 03.10 FT 045 Rev 09.pdf
